TRAXXAS 95076-4 Sledge 1/8 scale 4WD brushless monster truck. Fully assembled, RTR with TQi 2.4GHz radio system, VXL-6s power system, and ProGraphix clipless body.

Introduction

Engineered. Tested. Built to a higher standard. The all-new Sledgeis made to exceed your expectations for quality, toughness, and fun. The rock-solid chassis, massive steel drivetrain, ferocious 6s power, and race-inspired handling leave everything else in the dust.

Features:

• 1/8th Scale basher designed specifically for 6S power
• 20% larger and 75% thicker drive gears
• Triangulated chassis structure for superior chassis strength
• Remove and replace the body in just seconds with exclusive clipless body
• Includes a high-performance metal gear servo that produces over 347oz-in of torque
• 6S power system for brutal power
• Durable Sledgehammer tires are used for great handling and traction

Specifications:

• Truck:
• Length (including wing):23.78 inches (604mm)
• Front Track:18.10 inches (459mm)
• Rear Track:18.10 inches (459mm)
• Ground Clearance:1.95 inches (50mm)
• Weight (no battery):12.74 pounds (5.77kgs)
• Height (overall):8.43 inches (214mm)
• Wheelbase:15.10 inches (384mm)
• Shock Length (front):5.12 inches (128mm)
• Shock Length (rear):5.67 inches (144mm)
• Tire Diameter:6.7 x 3.3 inches (170mm x 84mm)
• Wheel Diameter:3.8 inches (97mm)
• Overall Drive Ratio:17.2 (13/52 motor pinion and spur gear)
• Differential Type:Sealed, hardened steel bevel, limited slip
• ESC:
• Model:Velineon VXL-6s
• Input Voltage (cells):4s6s LiPo (max: 25.2 volts)
• BEC Voltage:6.0 V
• BEC Current Continuous:10 A
• BEC Current Peak:20 A
• Reverse Delay:Yes, with lockout
• Motor:
• Type:2000 kV sensorless brushless
• Connector Type:Traxxas 6.5mm bullet connectors

Includes:

• (1) Traxxas RTR Sledge Monster Truck
• (1) TQi 2.4GHz radio system
• (1) Jumper plug (for 4s battery use)
• (1) Quick Start Guide
• High quality maintenance tools

Needed to Complete:

• 4S:(1) 4S 6700mAh LiPo Battery with Traxxas iD Connector or (2) 2S 7600mAh LiPo Batteries with Traxxas iD Connectors
• 6S:(2) 3S 5000mAh LiPo Batteries with Traxxas iD Connector
• (1) Compatible LiPo Balance Charger
• (4) AA Batteries

Manual

Traxxas Sledge Exploded View and Parts List
